Online Gas Analyzer Dust CEMS Continuous Emission Monitoring System For HCl CO

Brand Name:	JUGE
Model Number:	AG-DUST07
MOQ:	1 Unit
Price:	USD20000-50000
Packaging Details:	Neutral carton
Payment Terms:	Online order,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Nanjing, China

Certification:

IOS9001, CE

Product Name:

CEMS For HCl CO

Range:

0-50mg/m3-10g/m3 OEM

Accuracy:

2mg/m3

Error:

≤±2%F.S

Sample Condition:

Temperature Max 300 Celsius

Display Mode:

128*64 LCD

Applicable Stack Size:

1-15m

Power:

DC24V

Supply Ability:

100 Unit/Week

Highlight:

HCl CO cems monitoring system

Continuous Particulate Matter Emission Monitoring System

Product Description

Online Gas Analyzer Dust CEMS Continuous Particulate Matter Emission Monitoring System

>>Overview

It consists of three basic components: the particulate matter monitoring unit (dust), the flue gas parameter monitoring unit (temperature, pressure, flow rate, O2, humidity), and the data acquisition and processing unit.

The smoke and dust are extracted into the measurement chamber through high-temperature heating. The embedded high-stability laser light source irradiates the smoke particles, and the intensity of the laser scattering signal is positively correlated with the concentration of the smoke particles being irradiated. The instrument detects the weak light scattering signals (intensity signals and pulse signals), and through specific algorithms, the concentration of smoke and dust can be calculated.

>>Feature
1) LCD display for direct reading of dust concentration.
2) Extractive laser forward scattering design, unaffected by operating conditions.
3) High precision, good stability, and fast response time of the sensor.
4) Single-end installation with automatic dual-range switching and low detection limit.
5) Modular design with fault alarm codes for easy maintenance and repair.
6) Supports RS485/standard analog output and local dynamic regulatory control.

>>Principle
Optical Section:
1. The optical system comprises a laser light source, power control unit, photoelectric sensing module, and scattered light reception unit.
2. A 650 nm laser beam is emitted at a slight angle into the emission source. The interaction between the laser beam and smoke/dust particles generates scattered light, with backscattered light entering the sensor through the reception system and being converted into electrical signals for processing.
Circuit Section:
1. Implements functions including photoelectric conversion, laser beam modulation, signal amplification, demodulation, light source power control, V/I conversion, and HMI display.
2. Calibrator: Generates stable optical signals to perform zero-point calibration and range calibration for the instrument.

>>Main technical parameters

Dimensions & Weight: Φ158×275 mm / 5 kg
Environmental Requirements:
- Temperature: -40ºC to 65ºC
- Humidity: 0-100% RH
Measurement Error: ±2% FS
Media Conditions:
- Temperature: Up to 300ºC (Customizable for higher temperatures)
Display: 128×64 Graphic LCD
Signal Output: (4-20) mA
Maximum Load: 500 Ω
Sensitivity: 2 mg/m³
Measurement Range:
- Low: 0-50 mg/m³
- High: 0-10 g/m³ (Customizable ranges available)
Applicable Stack Size: 1-15 m
Power Consumption: 3 W
Power Supply: DC 24 V ±10%
